High welding stability; more than 30% power saving, low operating cost; three-phase power supply balanced input, power factor up to 95%; lower welding current and electrode pressure; almost no inductive energy loss in the secondary circuit; electrode life is more than doubled, reducing electrode grinding time; greatly saving the installation cost of power installation and auxiliary facilities such as water and gas; more accurate, faster and safer control and analysis of welding parameters; shorter welding time, improved work efficiency and welding quality.
Product function: wider welding range, better welding effect on low carbon steel, stainless steel, copper, aluminum and galvanized sheet.
Rated power: 160KVA
Maximum welding current: 40KA
Input voltage: 380 3PH
Duty cycle: 50%
Electrode pressure: 18KN
Electrode stroke: 100mm
